Vectorworks Tutorial: 3D Modeling Basics
Learn the foundational 3D modeling operations in Vectorworks: Extrude, Add Solids, Subtract Solids, Intersect Solids, Section Solids, Multiple Extrude, Sweep, Split, and Extrude Along Path.
What to notice
Notice how flat profiles become volume through command order, selection order, Z height, stacking order, and path direction.
3D modeling starts as a command vocabulary. A 2-foot by 2-foot rectangle at the origin becomes a way to see how the Model menu and 3D tool set turn flat geometry into editable volume.
Extrude is the first move: a 2D rectangle becomes a four-foot-tall object, and the Object Info palette shows the X, Y, Extrude, and bottom Z values that control its position in space.
The solid operations come next. Add Solids combines selected volumes. Subtract Solids removes one volume from another based on the selected direction. Intersect Solids keeps only the overlapping volume. Edit Solid keeps earlier operations available for adjustment.
Section Solids, Multiple Extrude, Tapered Extrude, Sweep, Split, and Extrude Along Path expand that vocabulary. The recurring idea is that the starting 2D shape, object order, Z-plane position, and path/profile relationship determine the final form.
Use Model menu commands to create volume
Extrude, Multiple Extrude, Tapered Extrude, Sweep, and Extrude Along Path each turn 2D geometry into a different kind of 3D form.
The command determines how the profile becomes volume.
Modeling grammar
2D profiles become volume through command order.
Plane, Z height, selection order, stacking order, path direction, and profile location all change the model the command produces.
PROFILE
Start with the 2D shape that defines the volume
Extrude, sweep, multiple extrude, and tapered extrude all begin with readable 2D geometry.
ORDER
Selection order changes solid operations
Add, subtract, intersect, and section solids depend on which object is selected and how the cut is directed.
PATH
Centerline and path direction matter
Extrude Along Path behaves best when the profile and path are positioned with intent.
One guiding idea
“Most complex 3D forms are a few simple operations used in the right order.”
01
Extrude makes the Z plane visible
In Top/Plan, the first extrude can look like nothing happened. The object becomes clear only when the view changes into 3D and the Object Info palette shows a four-foot extrusion sitting on the Z plane.
That moment matters because it connects 2D drafting to 3D space. The rectangle still has X and Y dimensions, but it now has height and a bottom Z value that can lift it above the plane.
02
Add, Subtract, and Intersect Solids each answer a different volume problem
Add Solids combines two selected solids into one object. Subtract Solids removes one selected volume from another and depends on which object is highlighted as the subtracting direction. Intersect Solids removes everything except the shared overlap.
Edit Solid can reopen the previous iteration. That is an important modeling habit: solid operations are not just final shapes, they can preserve a history that remains adjustable.
03
Profile, order, and path control the advanced forms
Multiple Extrude depends on stacking order. The top object in the stack becomes the top profile and the bottom object becomes the bottom profile. A locus point can even become the top profile for a pyramid-like form.
Sweep depends on a profile rotating around a center. Extrude Along Path depends on the relationship between the profile and the path, including the centerline offset needed when a trim profile should land on an edge instead of its own center.
Supporting material
Related resources and quick references stay close to the article so the writing can keep moving without hiding the practical details.
Open these when the topic needs more context: software documentation, adjacent lessons, or reference material that supports the workflow.
Potential exam questions
These prompts are written for study or LMS use. They are intentionally presented without answers so they can support learning, review, or Canvas integration without giving the result away on the page.
Question 01 of 03
What does an extrude do?
