Vectorworks Tutorial: Understanding Classes
Learn how classes control object appearance, attributes, hierarchy, and visibility across a scenic drafting file.
What to notice
Notice how classes control appearance and visibility without moving geometry. Layers organize where drawing systems live; classes control how objects read.
Classes are the graphic control system of a Vectorworks file. They do not hold the drawing the way design layers do; they define how objects look, organize, and show, gray, or hide across saved views, viewports, and drawing contexts.
A strong class system lets a file stay visually legible even as the drawing becomes dense. Line weights, fills, textures, and visibility can be managed consistently instead of adjusted object by object.
Scenic drafting depends on that control because drawings mix architecture, dimensions, scenic objects, masking, notes, and 3D elements. Classes let those categories behave predictably across views.
Let classes carry attributes
Class attributes are powerful because they standardize linework, fills, and textures across objects.
Use at Creation turns the class into a style rule instead of a label.
Graphic standards
Classes are visibility and attribute rules, not geometry containers.
Layers hold drawing context. Classes control how objects look and whether they can be seen across views.
HIERARCHY
Use names to keep categories readable
Hyphenated class names create a structure that can be scanned, filtered, and taught.
ATTRIBUTES
Let Use at Creation carry the standard
Line weight, fill, texture, and line type become class behavior instead of memory work.
GROUPS
Grouped objects still keep class behavior
A group can contain objects that respond differently when class visibility changes.
One guiding idea
“Classes make a drawing easier to trust because graphic standards stop depending on memory.”
01
Classes describe graphic behavior
A class is not a place where an object lives. It is a set of graphic and visibility instructions that can travel with that object across the file.
That difference is what separates classes from design layers. Layers organize drawing planes. Classes organize how objects appear and whether they are visible in a given view.
02
Use at Creation keeps standards intact
When class attributes are used at creation, an object can inherit the correct line weight, fill, color, texture, or visibility behavior automatically.
That makes the drawing more consistent and easier to revise. Instead of selecting dozens of objects to fix a graphic standard, the class can carry the standard for the whole category.
Supporting material
Related resources and quick references stay close to the article so the writing can keep moving without hiding the practical details.
Open these when the topic needs more context: software documentation, adjacent lessons, or reference material that supports the workflow.
Potential exam questions
These prompts are written for study or LMS use. They are intentionally presented without answers so they can support learning, review, or Canvas integration without giving the result away on the page.
Question 01 of 03
What is the primary role of a class in Vectorworks?
